Control and Reducer Panels

Control and Reducer Panels

Installation, Equipment for Supply Conduits (Gas, Compressed Air, Oxygen, Water, Electricity etc)
Control and Reducer Panels
Control and Reducer Panels
Control and Reducer Panels

Information

The 2nd stage pressure regulator unit controls and isolates the medical gases (O2, N2O, Air, CO2) that feed the gas outlets. It is suitable for flash or chased distribution networks, contains reducers, shut-off valves (upstream and downstream of reducers), pressure gauges, gas-specific connectors and low-high pressure switches, according to EN ISO 7396-1, HTM 02-01 and NFPA 99 standards. The AVSU are fitted to all medical gas and vacuum services in a prominent and accessible position at the entry of wards, theatres, intensive care, recovery rooms, etc. The AVSU panel is conforming to EN ISO 7396-1, HTM 02-01 and NFPA 99 standards and contains: • Shut-off valves (for Oxygen use) • Pressure/Vacuum gauges • Gas-specific connectors • Pressure sensors (digital or transducer) all placed inside a metal box galvanized and coated with electrostatic paint.
G. Samaras S.a.N31.D59G. Samaras is an international multi-regional company, active in the medical gases systems field since 1968. The company's headquarters, are located in the Industrial Area of Thermi, Thessaloniki, Greece, occupying a building of 4.500m2 and its branch, which supports service activities at Athens, Greece. Over the years, G. Samaras has established a strong reputation, thanks to its professionalism, reliability, and responsibility. The company's core values (quality, durability) the range of its products and services, the know-how on medical gas supply systems, along with the company's flexibility, are the company's competitive advantages over the years. G. Samaras has shown an exceptional growth rate, by developing an extensive sales network in more than 85 countries all over the world. Among the company's product portfolio, there are options like: Terminal Units Bed Head Units Pendant Arms Cylinder Stations for Medical Gases (Manifolds) Air Compressors System for Breathing Air Medical Vacuum Central Station Anesthetic Gases Scavenging System Medical O2 Oxygen Concentrators Supply Systems (O2 Generators), Medical Alarm Panels Control & Reducer Panels
